T055/T056/T057/T058
SiRON
8536901100
类型选择参考
| 模型 | T055 | T056 | T057 | T057-K | T058 | T058-K |
| 姓名 | 10位端子块 | 20位端子块 | 34位端子块 | 40位端子块 | ||
合适的PLC
松下
| 钥匙 | KV-B16XAXC | KV-C32XA/c | KV-1000 KV-3000 | ||
| 小PLC的KVSeries | KV-C64XA/c | KV-5000 KV-H20S KV-H40S | |||
| KV-C32TA/c | |||||
| KV-C64TA/c | |||||
| 松下 | FPO-C16T/C16CT | FPG-XY64D2T/P FP2-C1D | |||
| FPO-C16P/C16CP | FP2-X32D2 | ||||
| FPO-C32T/C32CT/T32CT | FP2-X64D2 | ||||
| FPD-C32P/C32CP/T32CP FPO-E16T/p | FP2-32T/p | ||||
| FPO-E32T/P FPO-E8X | FP2-Y64T/p | ||||
FPO-E16X FPZ-C28 FPZ-C32 | FP2-XY64D2T/XY64D7T | ||||
| FPO-C16T/C16CT | FP2-XY64D2P/XY64D7P FP2-PP21 | ||||
| FPO-C16P/C16CP | FP2-PP22 | ||||
| FPO-C32T/C32CT/T32CT | FP2-PP41 | ||||
| FPO-C32P/C32CP/T32CP FPO-E16T/p | FP2-PP42 | ||||
| FPO-E32T/P FPO-E8YT | FP2-HSCT | ||||
| FPO-E16YT FPZ-C32 | fp2-pxyt | ||||
| FPZ-C28 | |||||
| 奥隆 | CJ1W-MD232 CJ1W-MD233 | CJ1W-ID231 CJ1W-OD232 CJ1W-ID261 CJ1W-OD233 CJ1W-MD261 CI1W-OD262 CJ1W-ID232 CI1W-OD263 CI1W-ID262 CJ1W-MD263 CJ1W-MD263 CJ1W-MD563 CJ1W-MD563 CJ1M-CPU21 CJ1W-OD231 CJ1M-CPU22 CJ1W-OD261 CJ1M-CPU23 CJ1W-MD261 | |||
| mtsubishi | FX1NC-16MT FX1NC-32MT FX2NC-16MT FX2NC-32MT FX3UC-32MT FX2NC-16EX FX2NC-16EX-CFX2NC-16EXL-C FX2NC- FX2NC -16EYT FX2NC FX2NC-17EYT-C- 17EYT-C FX2N-10PG FX2N-10PG FX2N-10PG FX2N-10GM FX2N-10GM FX2N-10GM FX2N-10GM FX2N-10GM20GM20N-50GM FX2N-10GM | QX41 QX72 QX41-S1 QY41P QX42 QY42P QX42-S1 QY71 QX71 QH42P QH42P QD70P4 QD70D QD70D QD70P QD75M | |||
| 西门子 | 40p插头带有Afull范围 | ||||
| 横川 | F3WD64-3N F3WD32-3F F3WD64-3F | ||||
合适的电缆
合适的电缆： x 2 0 0 -1 x 2 1 0-1 x 2 1 6 -1 x 2 1 6-2，x 2 0 0 0 -2 x 2 1 0-2 x 2 1 8 -1 x 2 1 8 -1 x 2 1 8-9，x 2 0 0 0 0 -3 x 2 1 0-3，x 2 1 0-3，x 2 1 0 -4
有关详细信息，请参阅目录电缆系列
规格
| 输入 | 名义操作电流 | 1a | ||||
| 标称线圈电压 | DC24V | |||||
| 相应的输出设备 | 按钮开关，光电开关，电磁阀，指示器，垫脚伺服电机等。 | 伺服电动机控制信号线电路。 | 按钮开关，光电开关，电磁阀，指示器，垫脚伺服电机等。 | |||
